SCS 900
The SCS 900 model is an automatic change-over unit that controls and operates television transmitters and transposers, both analogue and digital, as well as microwave links, with configurations ranging from 1+1 to 8+1.All dialogues with controlled units take place through an ultimate generation microprocessor.
The System management has been made extremely simple thanks to multiple local or remote interfaces (RS-232, RS-485, parallel contacts, SNMP, USB and LAN).
The user may select either the manual or automatic mode and on/off or switching functions may be activated remotely.
• From 1 to 8 programs/channels + one back-up.
• Local/remote control.
• Automatic/manual mode.
• USB, RS-232, RS-485, LAN, SNMP management interface, parallel contacts.
• Management of switching delay.
• Memorization of events and alarms.
• Incorporated Real Time Clock.
• Priority management.
• Threshold levels and number of retries may be adjusted by user.
• Operative frequency: DC to1 GHz.
• Compact size: 3 RU (19”).
